Location:Home  >  Product center  >  TFT display screen  >  Wide View TFT Display Screen  >  2.4寸TFT彩屏 /240*320分辨率 /全視角IPS工藝 /MCU接口 /TFT-H024A1QVIST8N40
  • Model : 2.4 inch TFT color screen /240*320 resolution /full viewing angle IPS process /MCU interface /TFT-H024A1QVIST8N40

    Product type:TFT horizontal screen

    Show contents:240x320

    Outline size(mm) :42.72x60.26x3.20

    Size of View Window(mm):2.4

    Display size(mm) :2.4

    Effective size(mm):36.72x48.96

    Product application:Outdoor Instrumentation

    Visual angle:Full view

    Backlight type or brightness:1500cd/m2

    Connection PIN Number:40PIN

    Interface mode:MCU

    Special instructions:With CTP capacitive touch chip FT6236U

    Working temperature:-30~80℃

    Power supply voltage:3.3V

    Driver chip model:ST7789V

    PDF download
Product description

Product Description The TFT-H024A1QVIST8N40 is a 2.4-inch wide temperature IPS TFT-LCD display with a projected capacitive touchscreen with a resolution of 240x320 pixels. The module has built-in ST7789V driver IC and supports MCU interface. TFT-H024A1QVIST8N40 adopts IPS panel, which has the advantage of wider viewing angle, left: 80 / right: 80 / top: 80 / bottom: 80 degrees (typical), contrast ratio 800:1 (typical), brightness 1500 nits (typical) value), glare panel, 16:9 aspect ratio. The touch screen has built-in FT6236U IC, which supports I2C interface and multi-touch function. The H024A1 model has a projected capacitive touch panel (PCAP) but no touch panel option (TFT-H024A1QVIST8N40). The supply voltage (VCC) of the TFT-H024A1QVIST8N40 is 3.0V to 3.6V, with a typical value of 3.3V. It can work at temperatures from -30°C to +80°C and storage temperatures from -30°C to +80°C.
