Location:Home  >  Product center  >  TFT display screen  >  Wide View TFT Display Screen  >  掌機3.5寸TFT顯示屏/640x480分辨率/全視角/MIPI接口/工業級/TFT-H035A8VGIST6N30
  • Model : 3.5 inch TFT /640x480 resoliution/Full view/MIPI interface/Industrial grade/TFT-H035A8VGIST6N30

    Product type:TFT LCD

    Show contents:640x480

    Outline size(mm) :74.5x62.4x2.37

    Size of View Window(mm):3.5

    Display size(mm) :3.5

    Effective size(mm):74.5x62.4x2.37

    Product application:Instruments and apparatus

    Visual angle:Full View

    Backlight type or brightness:650cd/m2

    Connection PIN Number:FPC-30PIN

    Interface mode:MIPI

    Special instructions:Anti-static ESD 8KV

    Working temperature:-20~70℃

    Power supply voltage:2.8v

    Driver chip model:ST7703

Product description

Product Description The TFT-H035A8VGIST6N30 is a 3.5-inch full-color TFT LCD module with a resolution of 640x480 pixels and an aspect ratio of 1.25:1. The TFT module adopts ST7703 driver IC and supports MIPI interface. The TFT module with IPS panel has the advantage of wide viewing angle (left 80 degrees/right 80 degrees/up 80 degrees/down 80 degrees), a typical contrast ratio of 800:1, and a module brightness of up to 650 nits (typical). The working temperature range of the module is -20℃~+70℃, and the storage temperature range is -30℃~+80℃.
