Location:Home  >  Product center  >  TFT display screen  >  An on-board & Special TFT Module  >  4寸彩色高清液晶顯示模塊IPS 720X720點陣彩屏模組 NV3052 RGB 陽光下可見 TFT-H040A20DKINV 6N40
  • Model : 4.0 inch color HD LCD module IPS 720X720 dot matrix color screen module NV3052 RGB visible under sunlight TFT-H040A20DKINV 6N40

    Product type:TFT Square

    Show contents:720x720

    Outline size(mm) :78.98x74.83

    Size of View Window(mm):4.0

    Display size(mm) :4.0

    Effective size(mm):71.928x71.928

    Product application:Industrial Control Equipment

    Visual angle:Full view

    Backlight type or brightness:600cd/m2

    Connection PIN Number:40pin

    Interface mode:RGB

    Special instructions:Anti-static ESD 8KV

    Working temperature:-20~70℃

    Power supply voltage:3.3V

    Driver chip model:NV3052

Product description

TFT-H040A20DKINV 6N40 | 4.0" IPS LCD | 720x720px screen | EMI shielding | RGB interface | Optional capacitive touch screen, resistive touch screen

This 4.0-inch IPS TFT display has a resolution of 720x720 pixels and features an upgraded FPC design with EMI shielding on the cables. Also included is a high-brightness LED backlight with 600 cd/m2 brightness. Thanks to the IPS technology built into this LCD monitor, the monitor offers stunning clarity, superior color reproduction, better image consistency, and high contrast ratio across all viewing angles. The ultra-bright backlight and 3M enhancement film make this TFT sunlight-readable in bright conditions, including direct sunlight. Optional capacitive touch screen, resistive touch screen

The TFT also features a 24-bit RGB interface for seamless integration and compatibility with various Arduino/C8051 models. The LCD features a 40-pin FFC (Flexible Flat Cable) connection ensuring easy electrical connection. This TFT display is powered by a built-in NV3052 driver IC, which provides excellent performance and reliability. This driver optimizes the monitor's functionality, ensuring smooth operation and accurate rendering of images and graphics. Our monitors are RoHS compliant and adhere to strict environmental and safety standards.
