Location:Home  >  Product center  >  TFT display screen  >  Wide View TFT Display Screen  >  5.5寸TFT彩屏 | 720x1280高清 | 1000亮度 | MIPI接口 | TFT-H055A1HDIIL3N30
  • Model : 5.5 inch TFT Display | 720 x1280 HD | 1000 brightness | MIPI interface | TFT-H055A1HDIIL3N30

    Product type:TFT DISPLAY

    Show contents:720x1280

    Outline size(mm) :71.04x129.56

    Size of View Window(mm):5.5

    Display size(mm) :5.5

    Effective size(mm):67.932x120.768

    Product application:hand-held terminal

    Visual angle:Full view

    Backlight type or brightness:1000 cd/m2

    Connection PIN Number:30pin

    Interface mode:MIPI

    Special instructions:Optional Cap Touch

    Working temperature:-20~70℃

    Power supply voltage:3.3V

    Driver chip model:ILI9881

Product description

Product Description

TFT-H055A1HDIIL3N30 is a 5.5-inch 720x1280 full-color HD high-definition TFT LCD module. This TFT-LCD supports MIPI DSI interface and adopts wide viewing angle IPS (In-plane Switching) panel technology. Vivid, high-quality picture with saturated naturalness. This model has an operating temperature of -20°C to +70°C and a storage temperature of –30°C to +80°C. The size of this TFT module is 67.932x120.768mm, the size of the Active area (AA area) is 71.04x129.56 mm, the module has a built-in driver IC ILI9881 (driver IC), and the working power supply voltage: 3.3V. The TFT-H055A1HDIIL3N30 module is in the straight screen mode, if you need to use the horizontal screen mode, please contact us, and we will provide relevant technical support services.
